LG50DT内燃平衡重式叉车参数
动力形式.......................................柴油
额定载荷(kg)...................................5000
载荷中心距(mm)..................................600
最大起升高度(mm)...............................3000
自由起升高度(mm)................................200
货叉尺寸(mm)..........................1070×150×55
门架倾角(deg)..................................6/12
最小转弯半径(mm)...............................3370
最小直角通道宽度(mm)...........................3000
最大行驶速度(满载/空载)(km/h).................27/27
最大起升速度(满载/空载)(mm/s)...............330/450
最大爬坡度(%)....................................20
前悬距(mm)......................................595
后悬距(mm)......................................650
自重(kg).......................................8700
轮距(前轮/后轮)(mm).......................1040/1700
轴距(mm).......................................2250

外形尺寸
总长(含货叉)(mm)...............................4720
总宽(mm).......................................2000
门架起升高度(mm)...............................2500
安全架高度(mm).................................2500

最小离地间隙
门架(mm)........................................216
车架(mm)........................................248
